Thornton College. Late 19th century plan of ground floor, showing the three main periods of building
  1. Billiard room 22' 9" x 21' 8"
  2. Dressing room
  3. Bedroom
  4. Morning room 23' 0" x 22' 9"
  5. Library 37' 3" x ?
  6. W.C.
  7. Bedroom
  8. Smoking room 24' 5" x 13' 5"
  9. Lobby
  10. Linen room
  11. Housekeeper's room
  12. Kitchen
  13. Scullery
  14. Larder
  15. Game larder
  16. Dairy
  17. Bakehouse
  18. Laundry
  19. Brewhouse
  20. Store
  21. Still room
  22. Housemaid's room
  23. Coal store
  24. Wood store
  25. Butler's room
  1. Conservatory
  2. Banqueting hall 38' 0" x 23' 9"
  3. Open courtyard
  4. China Store
  5. Lamp room
  6. Butler's pantry
  7. Butler's bedroom
  8. Plate store
  9. Servant's hall
  10. Brushing room
  11. Open courtyard
  12. Main hall (with armorial glass)
  13. South drawing room 32' 2" x 23' 8"
  14. North drawing room 34' 1" x 20' 4"
  15. Main entrance hall
  16. Study 14' x ?
  17. Small dining room 23' 8" x ?
  18. Knife room
  19. Oil store
  20. Wine store
  21. Boot room
  22. Gun room
  23. W.C.
  24. Cloister
